This Shield allows you to connect an STM32 NUCLEO 144 F429ZI or F439ZI card to your panels in order to manufacture your PIN2DMD, it has 2 buttons to configure the type of panel (RGB, GRB, BRG…) as well as the brightness.
Here you are with your RIG MASTER in your fingers, here’s how to configure and install it. Here are the first recommendations before you start: You should never interconnect the GND KLs with the GND TOYS, otherwise you will remove the optoelectronic protection from the card, and you will endanger your PC.Each output accepts 5 Amps maximum, 48 Volts maximum.The […]
Here are some examples of « typical » Kits that will allow you to give you an idea of the configuration that suits you and that will answer questions that I am often asked … Basic no toys 1 KL25Z 1 KL Shield This simply allows you to connect the input buttons, properly, and possibly to connect a ball lance.The movements carried […]
I will try to explain to you what each board I sell on this site is used for. KL SHIELD Do you know the KL25Z , this card which is the heart of your Pincab?The KL SHIELD will facilitate and secure the wiring of your KL25Z by inserting it into the pins of the latter, and thus provide you with sockets on each input and output […]
CREDITS AND ACKNOWLEDGMENTS Writing + creation: Arnoz Based on the work of MJR: http://mjrnet.org/pinscape/ Please do not copy or publish this document without the prior permission of the author. PRESENTATION OF THE CARD: a – The MOLLUSK This card is an expansion card that allows you to add PWM ports to a KL25Z under Pinscape.It is designed to receive […]
